| enum | DrawFlags {
kNoDrawFlags = 0x0000
, kDrawBackfaces = 0x0001
, kDrawHatchGroup = 0x0002
, kDrawFrontfacesOnly = 0x0004
,
kDrawGradientFill = 0x0008
, kDrawSolidFill = 0x0010
, kDrawNoLineWeight = 0x0020
, kDrawNoPlotstyle = 0x0080
,
kDrawContourFill = 0x08000
, kDisableLayoutCache = 0x10000
, kDrawBoundaryForClipping = 0x20000
, kDrawBoundaryForClippingDrw = 0x40000
,
kClipSetIsEmpty = 0x80000
, kDrawPolygonFill = 0x100000
, kExcludeFromViewExt = 0x200000
, kDrawDgLsPolyWithoutBreaks = 0x400000
,
kPolygonProcessing = 0x800000
, kDisableAutoGenerateNormals = 0x1000000
, kDisableFillModeCheck = 0x2000000
, kDrawUnderlayReference = 0x4000000
,
kLineStyleScaleOverride = 0x8000000
, kDisableDisplayClipping = 0x10000000
, kRegenTypeDependent2dDraw = 0x20000000
, kInternalDrawFlags = kDisableLayoutCache | kClipSetIsEmpty | kRegenTypeDependent2dDraw
,
kDrawGeometryForExtents = 0x04000
, kFxNoFillOnSelect = 0x40000000
, kInheritableDrawFlags
} |
| |
| enum | LockFlags {
kNoLockFlags = 0x00000000
, kLockColors = 0x00000001
, kLockLineWeight = 0x00000002
, kLockLineType = 0x00000004
,
kLockLineTypeScale = 0x00000008
, kLockLayer = 0x00000010
, kLockByBlockLayer = 0x00000020
, kKeepAuxDataAndLockFlags = 0x00000040
,
kInheritableLockFlags = kLockColors | kLockLineWeight | kLockLineType | kLockLineTypeScale | kLockLayer | kKeepAuxDataAndLockFlags
} |
| |
| enum | ShadowFlags { kShadowsCastAndReceive = 0
, kShadowsDoesNotCast = 1
, kShadowsDoesNotReceive = 2
, kShadowsIgnore = kShadowsDoesNotCast | kShadowsDoesNotReceive
} |
| |
| enum | SelectionFlags {
kNoSelectionFlags = 0
, kSelectionIgnore = 1
, kHighlightingGeometry = 2
, kHiddenInHighlight = 4
,
kFxSubentitySelection = 0x80
} |
| |
| enum | SubEntityHints {
kHint2DAttributes = 1
, kHint3DAttributes = 2
, kHintAllAttributes = kHint2DAttributes | kHint3DAttributes
, kHintSnapModeOn = 4
,
kHintDefaultState = kHintAllAttributes
} |
| |
| void | setColor (OdUInt16 color) |
| |
| void | setTrueColor (const OdCmEntityColor &color) |
| |
| void | setLayer (OdDbStub *layerId) |
| |
| void | setLineType (OdDbStub *lineTypeId) |
| |
| void | setSelectionMarker (OdGsMarker selectionMarker) |
| |
| void | setFillType (OdGiFillType fillType) |
| |
| void | setFillPlane (const OdGeVector3d *pNormal=0) |
| |
| void | setLineWeight (OdDb::LineWeight lineWeight) |
| |
| void | setLineTypeScale (double lineTypeScale=1.0) |
| |
| void | setThickness (double thickness) |
| |
| void | setPlotStyleName (OdDb::PlotStyleNameType plotStyleNameType, OdDbStub *pPlotStyleNameId=0) |
| |
| void | setMaterial (OdDbStub *materialId) |
| |
| void | setMapper (const OdGiMapper *pMapper) |
| |
| void | setVisualStyle (const OdDbStub *visualStyleId) |
| |
| void | setTransparency (const OdCmTransparency &transparency) |
| |
| void | setDrawFlags (OdUInt32 drawFlags) |
| |
| void | setLockFlags (OdUInt32 lockFlags) |
| |
| void | setSelectionGeom (bool bSelectionFlag) |
| |
| void | setShadowFlags (OdGiSubEntityTraits::ShadowFlags shadowFlags) |
| |
| void | setSectionable (bool bSectionableFlag) |
| |
| void | setSelectionFlags (OdGiSubEntityTraits::SelectionFlags selectionFlags) |
| |
| OdDbStub * | layer () const |
| |
| OdDbStub * | lineType () const |
| |
| OdGiFillType | fillType () const |
| |
| bool | fillPlane (OdGeVector3d &normal) |
| |
| OdDb::LineWeight | lineWeight () const |
| |
| double | lineTypeScale () const |
| |
| double | thickness () const |
| |
| OdDb::PlotStyleNameType | plotStyleNameType () const |
| |
| OdDbStub * | plotStyleNameId () const |
| |
| OdDbStub * | material () const |
| |
| const OdGiMapper * | mapper () const |
| |
| void | addLight (const OdDbStub *) |
| |
| OdCmTransparency | transparency () const |
| |
| OdUInt32 | drawFlags () const |
| |
| OdUInt32 | lockFlags () const |
| |
| bool | selectionGeom () const |
| |
| OdGiSubEntityTraits::ShadowFlags | shadowFlags () const |
| |
| bool | sectionable () const |
| |
| OdGiSubEntityTraits::SelectionFlags | selectionFlags () const |
| |
| | ODRX_DECLARE_MEMBERS (OdGiSubEntityTraits) |
| |
| virtual OdDbStub * | visualStyle () const |
| |
| virtual void | setSecondaryTrueColor (const OdCmEntityColor &color) |
| |
| virtual OdCmEntityColor | secondaryTrueColor () const |
| |
| virtual void | setLineStyleModifiers (const OdGiDgLinetypeModifiers *pLSMod) |
| |
| virtual const OdGiDgLinetypeModifiers * | lineStyleModifiers () const |
| |
| virtual void | setFill (const OdGiFill *pFill) |
| |
| virtual const OdGiFill * | fill () const |
| |
| virtual void | setAuxData (const OdGiAuxiliaryDataPtr &pAuxData) |
| |
| virtual OdGiAuxiliaryDataPtr | auxData () const |
| |
| virtual bool | pushLineweightOverride (const OdGiLineweightOverride *pOverride) |
| |
| virtual void | popLineweightOverride () |
| |
| virtual bool | pushPaletteOverride (const OdGiPalette *pOverride) |
| |
| virtual void | popPaletteOverride () |
| |
| virtual OdUInt32 | setupForEntity () const |
| |
| | ODRX_DECLARE_MEMBERS (OdGiDrawableTraits) |
| |
| | ODRX_HEAP_OPERATORS () |
| |
| | OdRxObject () |
| |
| virtual | ~OdRxObject () |
| |
| virtual OdRxObject * | queryX (const OdRxClass *pClass) const |
| |
| virtual OdRxObject * | x (const OdRxClass *pClass) const |
| |
| virtual OdRxClass * | isA () const |
| |
| virtual void | addRef ()=0 |
| |
| virtual void | release ()=0 |
| |
| virtual long | numRefs () const |
| |
| bool | isKindOf (const OdRxClass *pClass) const |
| |
| virtual OdRxObjectPtr | clone () const |
| |
| virtual void | copyFrom (const OdRxObject *pSource) |
| |
| virtual OdRx::Ordering | comparedTo (const OdRxObject *pOther) const |
| |
| virtual bool | isEqualTo (const OdRxObject *pOther) const |
| |
| static OdRxObjectPtr | cast (const OdRxObject *pointer) |
| |
| static OdRxClass * | desc () |
| |
| static void | rxInit () |
| |
| static void | rxUninit () |
| |
This class provides an implementation of the OdGisubEntityTraits::color() function.
- See also
- TD_Gi
<group OdGi_Classes>
Definition at line 60 of file GiLayerTraitsData.h.
Public Types inherited from
