#include <GiBaseVectorizer.h>

Inheritance diagram for OdGiWorldDrawImpl:

Public Member Functions
virtual void	setContext (OdGiContext *pUserContext)

OdUInt16	color () const

OdCmEntityColor	trueColor () const

OdDbStub *	layer () const

OdDbStub *	lineType () const

OdGiFillType	fillType () const

OdDb::LineWeight	lineWeight () const

double	lineTypeScale () const

double	thickness () const

OdDb::PlotStyleNameType	plotStyleNameType () const

OdDbStub *	plotStyleNameId () const

OdDbStub *	material () const

const OdGiMapper *	mapper () const

OdDbStub *	visualStyle () const

OdCmTransparency	transparency () const

OdUInt32	drawFlags () const

OdUInt32	lockFlags () const

bool	selectionGeom () const

ShadowFlags	shadowFlags () const

bool	sectionable () const

SelectionFlags	selectionFlags () const

OdCmEntityColor	secondaryTrueColor () const

const OdGiDgLinetypeModifiers *	lineStyleModifiers () const

const OdGiFill *	fill () const

OdGiAuxiliaryDataPtr	auxData () const

void	setTrueColor (const OdCmEntityColor &color)

void	setPlotStyleName (OdDb::PlotStyleNameType plotStyleNameType, OdDbStub *pPlotStyleNameId=0)

void	setColor (OdUInt16 color)

void	setLayer (OdDbStub *layerId)

void	setLineType (OdDbStub *lineTypeId)

void	setFillType (OdGiFillType fillType)

void	setLineWeight (OdDb::LineWeight lineWeight)

void	setLineTypeScale (double lineTypeScale)

void	setThickness (double thickness)

void	setSelectionMarker (OdGsMarker selectionMarker)

void	setMaterial (OdDbStub *pMaterialId)

void	setMapper (const OdGiMapper *pMapper)

void	setVisualStyle (const OdDbStub *visualStyleId)

void	setTransparency (const OdCmTransparency &transparency)

void	setDrawFlags (OdUInt32 drawFlags)

void	setLockFlags (OdUInt32 lockFlags)

void	setSelectionGeom (bool bSelectionFlag)

void	setShadowFlags (ShadowFlags shadowFlags)

void	setSectionable (bool bSectionableFlag)

void	setSelectionFlags (SelectionFlags selectionFlags)

void	setSecondaryTrueColor (const OdCmEntityColor &color)

void	setLineStyleModifiers (const OdGiDgLinetypeModifiers *pLSMod)

void	setFill (const OdGiFill *pFill)

void	setAuxData (const OdGiAuxiliaryDataPtr &pAuxData)

OdGiContext *	context () const

OdGiSubEntityTraits &	subEntityTraits () const

OdGiGeometry &	rawGeometry () const

OdUInt32	numberOfIsolines () const

Public Member Functions inherited from OdGiDummyCommonDraw< OdGiWorldDraw_ >
virtual OdGiRegenType	regenType () const

virtual bool	regenAbort () const

virtual bool	isDragging () const

virtual double	deviation (const OdGiDeviationType t, const OdGePoint3d &p) const

Public Member Functions inherited from OdGiWorldDraw_
OdGiWorldGeometry &	geometry () const

const OdGiPathNode *	currentGiPath () const

Public Member Functions inherited from OdGiWorldDraw
	ODRX_DECLARE_MEMBERS (OdGiWorldDraw)

Public Member Functions inherited from OdGiCommonDraw
	ODRX_DECLARE_MEMBERS (OdGiCommonDraw)

virtual bool	displayModelerSilhouettes () const

Public Member Functions inherited from OdRxObject
	ODRX_HEAP_OPERATORS ()

	OdRxObject ()

virtual	~OdRxObject ()

virtual OdRxObject *	queryX (const OdRxClass *pClass) const

virtual OdRxObject *	x (const OdRxClass *pClass) const

virtual OdRxClass *	isA () const

virtual void	addRef ()=0

virtual void	release ()=0

virtual long	numRefs () const

bool	isKindOf (const OdRxClass *pClass) const

virtual OdRxObjectPtr	clone () const

virtual void	copyFrom (const OdRxObject *pSource)

virtual OdRx::Ordering	comparedTo (const OdRxObject *pOther) const

virtual bool	isEqualTo (const OdRxObject *pOther) const

Public Member Functions inherited from OdGiWorldGeometry
	ODRX_DECLARE_MEMBERS (OdGiWorldGeometry)

virtual void	setExtents (const OdGePoint3d *newExtents)=0

virtual void	startAttributesSegment ()

Public Member Functions inherited from OdGiGeometry
	ODRX_DECLARE_MEMBERS (OdGiGeometry)

virtual OdGeMatrix3d	getModelToWorldTransform () const =0

virtual OdGeMatrix3d	getWorldToModelTransform () const =0

virtual void	pushModelTransform (const OdGeVector3d &normal)=0

virtual void	pushModelTransform (const OdGeMatrix3d &xfm)=0

virtual void	popModelTransform ()=0

virtual void	circle (const OdGePoint3d &center, double radius, const OdGeVector3d &normal)=0

virtual void	circle (const OdGePoint3d &firstPoint, const OdGePoint3d &secondPoint, const OdGePoint3d &thirdPoint)=0

virtual void	circularArc (const OdGePoint3d &center, double radius, const OdGeVector3d &normal, const OdGeVector3d &startVector, double sweepAngle, OdGiArcType arcType=kOdGiArcSimple)=0

virtual void	circularArc (const OdGePoint3d &firstPoint, const OdGePoint3d &secondPoint, const OdGePoint3d &thirdPoint, OdGiArcType arcType=kOdGiArcSimple)=0

virtual void	polyline (OdInt32 numVertices, const OdGePoint3d vertexList, const OdGeVector3d pNormal=0, OdGsMarker baseSubEntMarker=-1)=0

virtual void	polygon (OdInt32 numVertices, const OdGePoint3d *vertexList)=0

virtual void	polygon (OdInt32 numVertices, const OdGePoint3d vertexList, const OdGeVector3d pNormal)

virtual void	pline (const OdGiPolyline &polyline, OdUInt32 fromIndex=0, OdUInt32 numSegs=0)=0

virtual void	mesh (OdInt32 numRows, OdInt32 numColumns, const OdGePoint3d vertexList, const OdGiEdgeData pEdgeData=0, const OdGiFaceData pFaceData=0, const OdGiVertexData pVertexData=0)=0

virtual void	shell (OdInt32 numVertices, const OdGePoint3d vertexList, OdInt32 faceListSize, const OdInt32 faceList, const OdGiEdgeData pEdgeData=0, const OdGiFaceData pFaceData=0, const OdGiVertexData *pVertexData=0)=0

virtual void	text (const OdGePoint3d &position, const OdGeVector3d &normal, const OdGeVector3d &direction, double height, double width, double oblique, const OdString &msg)=0

virtual void	text (const OdGePoint3d &position, const OdGeVector3d &normal, const OdGeVector3d &direction, const OdChar msg, OdInt32 length, bool raw, const OdGiTextStyle pTextStyle)=0

virtual void	xline (const OdGePoint3d &firstPoint, const OdGePoint3d &secondPoint)=0

virtual void	ray (const OdGePoint3d &basePoint, const OdGePoint3d &throughPoint)=0

virtual void	nurbs (const OdGeNurbCurve3d &nurbsCurve)=0

virtual void	ellipArc (const OdGeEllipArc3d &ellipArc, const OdGePoint3d *endPointsOverrides=0, OdGiArcType arcType=kOdGiArcSimple)=0

virtual void	draw (const OdGiDrawable *pDrawable)=0

virtual void	pushClipBoundary (OdGiClipBoundary *pBoundary)=0

virtual void	popClipBoundary ()=0

virtual void	worldLine (const OdGePoint3d points[2])=0

virtual void	image (const OdGiImageBGRA32 &img, const OdGePoint3d &origin, const OdGeVector3d &uVec, const OdGeVector3d &vVec, OdGiRasterImage::TransparencyMode trpMode=OdGiRasterImage::kTransparency8Bit)=0

virtual void	edge (const OdGiEdge2dArray &edges)=0

virtual void	pushClipBoundary (OdGiClipBoundary pBoundary, OdGiAbstractClipBoundary pClipInfo)

virtual void	polypoint (OdInt32 numPoints, const OdGePoint3d vertexList, const OdCmEntityColor pColors, const OdCmTransparency pTransparency, const OdGeVector3d pNormals=NULL, const OdGsMarker *pSubEntMarkers=NULL, OdInt32 nPointSize=0)

ODRX_SEALED_VIRTUAL void	polypoint (OdInt32 numPoints, const OdGePoint3d vertexList, const OdCmEntityColor pColors, const OdGeVector3d pNormals=NULL, const OdGsMarker pSubEntMarkers=NULL) ODRX_FINAL

ODRX_SEALED_VIRTUAL void	polypoint (OdInt32 numPoints, const OdGePoint3d vertexList, const OdGeVector3d pNormals=NULL, const OdGsMarker *pSubEntMarkers=NULL) ODRX_FINAL

virtual void	polyPolygon (OdUInt32 numIndices, const OdUInt32 pNumPositions, const OdGePoint3d pPositions, const OdUInt32 pNumPoints, const OdGePoint3d pPoints, const OdCmEntityColor pOutlineColors=NULL, const OdUInt32 pOutlinePsLinetypes=NULL, const OdCmEntityColor pFillColors=NULL, const OdCmTransparency pFillTransparencies=NULL)

virtual void	rowOfDots (OdInt32 numPoints, const OdGePoint3d &startPoint, const OdGeVector3d &dirToNextPoint)

virtual void	pointCloud (const OdGiPointCloud &pCloud)

virtual bool	brep (const OdGiBrep &giBrep)

Public Member Functions inherited from OdGiSubEntityTraits
	ODRX_DECLARE_MEMBERS (OdGiSubEntityTraits)

virtual void	setFillPlane (const OdGeVector3d *pNormal=0)

virtual bool	fillPlane (OdGeVector3d &normal)

virtual bool	pushLineweightOverride (const OdGiLineweightOverride *pOverride)

virtual void	popLineweightOverride ()

virtual bool	pushPaletteOverride (const OdGiPalette *pOverride)

virtual void	popPaletteOverride ()

virtual OdUInt32	setupForEntity () const

virtual void	addLight (const OdDbStub *lightId)

Public Member Functions inherited from OdGiDrawableTraits
	ODRX_DECLARE_MEMBERS (OdGiDrawableTraits)

Static Public Member Functions
static OdGiContext *	dummyGiContext ()

Static Public Member Functions inherited from OdRxObject
static OdRxObjectPtr	cast (const OdRxObject *pointer)

static OdRxClass *	desc ()

static void	rxInit ()

static void	rxUninit ()

Protected Member Functions
	ODRX_USING_HEAP_OPERATORS (OdGiDummyCommonDraw< OdGiWorldDraw_ >)

	OdGiWorldDrawImpl ()

Protected Member Functions inherited from OdGiWorldDraw_
	ODRX_USING_HEAP_OPERATORS (OdGiWorldDraw)

Protected Attributes
OdGiSubEntityTraitsData	m_entityTraitsData

OdGiContext *	m_pContext

Additional Inherited Members
Public Types inherited from OdGiSubEntityTraits
enum	DrawFlags { kNoDrawFlags = 0x0000 , kDrawBackfaces = 0x0001 , kDrawHatchGroup = 0x0002 , kDrawFrontfacesOnly = 0x0004 , kDrawGradientFill = 0x0008 , kDrawSolidFill = 0x0010 , kDrawNoLineWeight = 0x0020 , kDrawNoPlotstyle = 0x0080 , kDrawContourFill = 0x08000 , kDisableLayoutCache = 0x10000 , kDrawBoundaryForClipping = 0x20000 , kDrawBoundaryForClippingDrw = 0x40000 , kClipSetIsEmpty = 0x80000 , kDrawPolygonFill = 0x100000 , kExcludeFromViewExt = 0x200000 , kDrawDgLsPolyWithoutBreaks = 0x400000 , kPolygonProcessing = 0x800000 , kDisableAutoGenerateNormals = 0x1000000 , kDisableFillModeCheck = 0x2000000 , kDrawUnderlayReference = 0x4000000 , kLineStyleScaleOverride = 0x8000000 , kDisableDisplayClipping = 0x10000000 , kRegenTypeDependent2dDraw = 0x20000000 , kInternalDrawFlags = kDisableLayoutCache \| kClipSetIsEmpty \| kRegenTypeDependent2dDraw , kDrawGeometryForExtents = 0x04000 , kFxNoFillOnSelect = 0x40000000 , kInheritableDrawFlags }

enum	LockFlags { kNoLockFlags = 0x00000000 , kLockColors = 0x00000001 , kLockLineWeight = 0x00000002 , kLockLineType = 0x00000004 , kLockLineTypeScale = 0x00000008 , kLockLayer = 0x00000010 , kLockByBlockLayer = 0x00000020 , kKeepAuxDataAndLockFlags = 0x00000040 , kInheritableLockFlags = kLockColors \| kLockLineWeight \| kLockLineType \| kLockLineTypeScale \| kLockLayer \| kKeepAuxDataAndLockFlags }

enum	ShadowFlags { kShadowsCastAndReceive = 0 , kShadowsDoesNotCast = 1 , kShadowsDoesNotReceive = 2 , kShadowsIgnore = kShadowsDoesNotCast \| kShadowsDoesNotReceive }

enum	SelectionFlags { kNoSelectionFlags = 0 , kSelectionIgnore = 1 , kHighlightingGeometry = 2 , kHiddenInHighlight = 4 , kFxSubentitySelection = 0x80 }

enum	SubEntityHints { kHint2DAttributes = 1 , kHint3DAttributes = 2 , kHintAllAttributes = kHint2DAttributes \| kHint3DAttributes , kHintSnapModeOn = 4 , kHintDefaultState = kHintAllAttributes }

Detailed Description

This class provides an implementation of the OdGiWorldDraw::geometry() function.

See also: TD_Gi

Definition at line 79 of file GiBaseVectorizer.h.

Constructor & Destructor Documentation

◆ OdGiWorldDrawImpl()

OdGiWorldDrawImpl::OdGiWorldDrawImpl ( )

protected

Member Function Documentation

◆ auxData()

OdGiAuxiliaryDataPtr OdGiWorldDrawImpl::auxData ( ) const

virtual

Retrieves pointer to auxiliary data context.

Returns: smart pointer to the auxiliary data context object.

Reimplemented from OdGiSubEntityTraits.

◆ color()

OdUInt16 OdGiWorldDrawImpl::color ( ) const

virtual

Retrieves entity color index (ACI).

Returns: Entity color index as OdUInt16 value.

See also: <exref target="https://docs.opendesign.com/td/cm.html">Working with Colors</exref>

Implements OdGiSubEntityTraits.

◆ context()

OdGiContext * OdGiWorldDrawImpl::context ( ) const

virtual

Retrieves context associated with this object.

Returns: Pointer to the associated context.

Implements OdGiCommonDraw.

◆ drawFlags()

OdUInt32 OdGiWorldDrawImpl::drawFlags ( ) const

virtual

Retrieves the current DrawFlags bitmask.

Returns: Draw bit flags as the OdUInt32 value.

Reimplemented from OdGiSubEntityTraits.

◆ dummyGiContext()

static OdGiContext * OdGiWorldDrawImpl::dummyGiContext ( )

static

Retrieves the OdGiContext instance associated with this object.

Parameters

pointer to the context associated with this object.

◆ fill()

const OdGiFill * OdGiWorldDrawImpl::fill ( ) const

virtual

Retrieves boundary filling parameters.

Returns: pointer to the instance of the OdGiFill class.

Reimplemented from OdGiSubEntityTraits.

◆ fillType()

OdGiFillType OdGiWorldDrawImpl::fillType ( ) const

virtual

Retrieves the current fill type.

Returns: One of the following values:

Value Description kOdGiFillAlways 1 Fill closed graphic primitives. kOdGiFillNever 2 Don't fill closed graphic primitives.

Closed graphic primitives consist of the following: arcs with (OdGiArcType == kOdGiArcSector) || (OdGiArcType == kOdGiArcChord) circles meshes polygons shells

Implements OdGiSubEntityTraits.

◆ layer()

OdDbStub * OdGiWorldDrawImpl::layer ( ) const

virtual

Retrieves the current layer.

Returns: Pointer to the OdDbStub that represents layer identifier.

See also: <link tv_working_with_attributes_layers, Work with Layers>

Implements OdGiSubEntityTraits.

◆ lineStyleModifiers()

const OdGiDgLinetypeModifiers * OdGiWorldDrawImpl::lineStyleModifiers ( ) const

virtual

Retrieves pointer to the current Dgn Line Style modifiers structure.

Returns: pointer to the OdGiDgLinetypeModifiers.

Reimplemented from OdGiSubEntityTraits.

◆ lineType()

OdDbStub * OdGiWorldDrawImpl::lineType ( ) const

virtual

Retrieves the current linetype.

Returns: Pointer to the OdDbStub that represents linetype identifier.

See also: <exref target="https://docs.opendesign.com/td/db_linetype.html">Working with Linetypes</exref>

Implements OdGiSubEntityTraits.

◆ lineTypeScale()

double OdGiWorldDrawImpl::lineTypeScale ( ) const

virtual

Retrieves the current linetype scale.

Returns: Linetype scale as a value of the double type.

See also: <exref target="https://docs.opendesign.com/td/db_linetype_properties.html">Specific Properties of Linetypes</exref>

Implements OdGiSubEntityTraits.

◆ lineWeight()

OdDb::LineWeight OdGiWorldDrawImpl::lineWeight ( ) const

virtual

Retrieves the current lineweight.

Returns: Current lineweight as an OdDb::LineWeight value.

See also: <link tv_working_with_attributes_lineweights, Work with Lineweights>

Implements OdGiSubEntityTraits.

◆ lockFlags()

OdUInt32 OdGiWorldDrawImpl::lockFlags ( ) const

virtual

Retrieves the current LockFlags bitmask.

Returns: Lock bit flags as the OdUInt32 value.

Reimplemented from OdGiSubEntityTraits.

◆ mapper()

const OdGiMapper * OdGiWorldDrawImpl::mapper ( ) const

virtual

Retrieves pointer to the current material mapper.

Returns: Pointer to the OdDbStub that represents a mapper identifier.

See also: <link tv_working_with_attributes_materials_mapping, Work with Mapping Properties>

Implements OdGiSubEntityTraits.

◆ material()

OdDbStub * OdGiWorldDrawImpl::material ( ) const

virtual

Retrieves the identifier of the material.

Returns: Pointer to the OdDbStub that represents a material identifier.

See also: <link tv_working_with_attributes_materials, Work with Materials>

Implements OdGiSubEntityTraits.

◆ numberOfIsolines()

OdUInt32 OdGiWorldDrawImpl::numberOfIsolines ( ) const

virtual

Retrieves count of isolines that are used to represent an entity.

Returns: number of isolines.

Remarks: Isolines are lines or curves which are used to represent the entity. For example, if an entity is a sphere and this method returns 3, the sphere should be displayed as 3 circles with a common center and planes that are perpendicular to each other.

Reimplemented from OdGiDummyCommonDraw< OdGiWorldDraw_ >.

◆ ODRX_USING_HEAP_OPERATORS()

OdGiWorldDrawImpl::ODRX_USING_HEAP_OPERATORS ( OdGiDummyCommonDraw< OdGiWorldDraw_ > )

protected

◆ plotStyleNameId()

OdDbStub * OdGiWorldDrawImpl::plotStyleNameId ( ) const

virtual

Retrieves object ID of the the plot style name.

Returns: Pointer to the OdDbStub that represents a plot style name identifier.

Implements OdGiSubEntityTraits.

◆ plotStyleNameType()

OdDb::PlotStyleNameType OdGiWorldDrawImpl::plotStyleNameType ( ) const

virtual

Retrieves the current PlotStyleName type.

Returns: One of the following values:

Value
kPlotStyleNameByLayer 0 kPlotStyleNameByBlock 1 kPlotStyleNameIsDictDefault 2 kPlotStyleNameById 3

Implements OdGiSubEntityTraits.

◆ rawGeometry()

OdGiGeometry & OdGiWorldDrawImpl::rawGeometry ( ) const

virtual

Retrieves raw geometry associated with this object.

Returns: raw geometry.

Remarks: The method cannot return NULL.

Implements OdGiCommonDraw.

◆ secondaryTrueColor()

OdCmEntityColor OdGiWorldDrawImpl::secondaryTrueColor ( ) const

virtual

Sets the current secondary color from an OdCmEntityColor instance.

Parameters

color [in] OdCmEntityColor object.

Reimplemented from OdGiSubEntityTraits.

◆ sectionable()

bool OdGiWorldDrawImpl::sectionable ( ) const

virtual

Retrieves the current sectionable flag.

Returns: true if geometry is the sectionable flag is used, false otherwise.

See also: <link tv_planarClip_sample, Planar Clipping Section Generation for a Custom Entity>

Reimplemented from OdGiSubEntityTraits.

◆ selectionFlags()

SelectionFlags OdGiWorldDrawImpl::selectionFlags ( ) const

virtual

Retrieves the current SelectionFlags.

Returns: One of the SelectionFlags enumeration values.

Reimplemented from OdGiSubEntityTraits.

◆ selectionGeom()

bool OdGiWorldDrawImpl::selectionGeom ( ) const

virtual

Retrieves the current selection geometry flag.

Returns: true if the selection geometry flag is used, false otherwise.

See also: <link tv_working_with_features_selections, Work with Selections>

Reimplemented from OdGiSubEntityTraits.

◆ setAuxData()

void OdGiWorldDrawImpl::setAuxData ( const OdGiAuxiliaryDataPtr & pAuxData )

virtual

Sets pointer to auxiliary data context.

Parameters

pAuxData [in] pointer to auxiliary data context.

Reimplemented from OdGiSubEntityTraits.

◆ setColor()

void OdGiWorldDrawImpl::setColor ( OdUInt16 color )

virtual

Sets the current color index (ACI).

Parameters

color [in] Color index.

Remarks: color must be one of the following:

Value Description kACIbyBlock 0 ByBlock. kACIforeground 7 Foreground color. kACIbyLayer 256 ByLayer. kACIRed 1 Red. kACIYellow 2 Yellow. kACIGreen 3 Green. kACICyan 4 Cyan. kACIBlue 5 Blue. kACIMagenta 6 Magenta. .. 8-255 Defined by AcadPalette.h

See also: <exref target="https://docs.opendesign.com/td/cm.html">Working with Colors</exref>

Implements OdGiSubEntityTraits.

◆ setContext()

virtual void OdGiWorldDrawImpl::setContext ( OdGiContext * pUserContext )

virtual

Sets the OdGiContext instance associated with this object.

Parameters

pUserContext [in] Pointer to the user context.

Reimplemented in OdGiExtCalc.

◆ setDrawFlags()

void OdGiWorldDrawImpl::setDrawFlags ( OdUInt32 drawFlags )

virtual

Sets the drawing flags.

Parameters

drawFlags [in] Input bitmask with DrawFlags.

Reimplemented from OdGiSubEntityTraits.

◆ setFill()

void OdGiWorldDrawImpl::setFill ( const OdGiFill * pFill )

virtual

Sets boundary filling.

Parameters

pFill [in] Boundary filling parameters.

Reimplemented from OdGiSubEntityTraits.

◆ setFillType()

void OdGiWorldDrawImpl::setFillType ( OdGiFillType fillType )

virtual

Sets the current fill type.

Parameters

fillType [in] Fill type.

Remarks: fillType must be one of the following:

Value Description kOdGiFillAlways 1 Fill closed graphic primitives. kOdGiFillNever 2 Don't fill closed graphic primitives.

Closed graphic primitives consist of the following: arcs with (OdGiArcType == kOdGiArcSector) || (OdGiArcType == kOdGiArcChord) circles meshes polygons shells

Implements OdGiSubEntityTraits.

◆ setLayer()

void OdGiWorldDrawImpl::setLayer ( OdDbStub * layerId )

virtual

Sets the current layer.

Parameters

layerId [in] Object ID of the LayerTableRecord.

See also: <link tv_working_with_attributes_layers, Work with Layers>

Implements OdGiSubEntityTraits.

◆ setLineStyleModifiers()

void OdGiWorldDrawImpl::setLineStyleModifiers ( const OdGiDgLinetypeModifiers * pLSMod )

virtual

Sets Dgn Line Style modifiers.

Parameters

pLSMod [in] Pointer to structure with Dgn Line Style modifiers.

Reimplemented from OdGiSubEntityTraits.

◆ setLineType()

void OdGiWorldDrawImpl::setLineType ( OdDbStub * lineTypeId )

virtual

Sets the current linetype.

Parameters

lineTypeId [in] Object ID of the LinetypeTableRecord.

See also: <exref target="https://docs.opendesign.com/td/db_linetype.html">Working with Linetypes</exref>

Implements OdGiSubEntityTraits.

◆ setLineTypeScale()

void OdGiWorldDrawImpl::setLineTypeScale ( double lineTypeScale )

virtual

Sets the current linetype scale.

Parameters

lineTypeScale [in] Linetype scale factor.

See also: <exref target="https://docs.opendesign.com/td/db_linetype_properties.html">Specific Properties of Linetypes</exref>

Implements OdGiSubEntityTraits.

◆ setLineWeight()

void OdGiWorldDrawImpl::setLineWeight ( OdDb::LineWeight lineWeight )

virtual

Sets the current lineweight.

Parameters

lineWeight [in] Lineweight.

See also: <link tv_working_with_attributes_lineweights, Work with Lineweights>

Implements OdGiSubEntityTraits.

◆ setLockFlags()

void OdGiWorldDrawImpl::setLockFlags ( OdUInt32 lockFlags )

virtual

Sets the lock flags.

Parameters

lockFlags [in] Input bitmask with LockFlags.

Reimplemented from OdGiSubEntityTraits.

◆ setMapper()

void OdGiWorldDrawImpl::setMapper ( const OdGiMapper * pMapper )

virtual

Sets the current material mapper.

Parameters

pMapper [in] Pointer to the GI mapper object.

See also: <link tv_working_with_attributes_materials_mapping, Work with Mapping Properties>

Implements OdGiSubEntityTraits.

◆ setMaterial()

void OdGiWorldDrawImpl::setMaterial ( OdDbStub * pMaterialId )

virtual

Sets the current material.

Parameters

materialId [in] Object ID of the material.

See also: <link tv_working_with_attributes_materials, Work with Materials>

Implements OdGiSubEntityTraits.

◆ setPlotStyleName()

void OdGiWorldDrawImpl::setPlotStyleName	(	OdDb::PlotStyleNameType	plotStyleNameType,
		OdDbStub *	pPlotStyleNameId = 0 )

virtual

Sets the current PlotStyleName.

Parameters

plotStyleNameType	[in] Plot Style Name Type.
pPlotStyleNameId	[in] Object ID of the Plot Style Name.

Remarks: plotStyleNameId is used only when plotStyleNameType == kPlotStyleNameById.

plotStyleNameType must be one of the following:

Value
kPlotStyleNameByLayer 0 kPlotStyleNameByBlock 1 kPlotStyleNameIsDictDefault 2 kPlotStyleNameById 3

Implements OdGiSubEntityTraits.

◆ setSecondaryTrueColor()

void OdGiWorldDrawImpl::setSecondaryTrueColor ( const OdCmEntityColor & color )

virtual

Sets the current secondary color from an OdCmEntityColor instance.

Parameters

color [in] OdCmEntityColor object.

Reimplemented from OdGiSubEntityTraits.

◆ setSectionable()

void OdGiWorldDrawImpl::setSectionable ( bool bSectionableFlag )

virtual

Sets sectionable flag.

Parameters

bSectionableFlag [in] New sectionable flag.

See also: <link tv_planarClip_sample, Planar Clipping Section Generation for a Custom Entity>

Reimplemented from OdGiSubEntityTraits.

◆ setSelectionFlags()

void OdGiWorldDrawImpl::setSelectionFlags ( SelectionFlags selectionFlags )

virtual

Sets the selection flags.

Parameters

selectionFlags [in] Input SelectionFlags.

Reimplemented from OdGiSubEntityTraits.

◆ setSelectionGeom()

void OdGiWorldDrawImpl::setSelectionGeom ( bool bSelectionFlag )

virtual

Sets selection geometry flag.

Parameters

bSelectionFlag [in] New selection geometry flag.

See also: <link tv_working_with_features_selections, Work with Selections>

Reimplemented from OdGiSubEntityTraits.

◆ setSelectionMarker()

void OdGiWorldDrawImpl::setSelectionMarker ( OdGsMarker selectionMarker )

virtual

Sets the current selection marker.

Parameters

selectionMarker [in] Selection marker.

Implements OdGiSubEntityTraits.

Reimplemented in OdGsBaseVectorizer.

◆ setShadowFlags()

void OdGiWorldDrawImpl::setShadowFlags ( ShadowFlags shadowFlags )

virtual

Sets the shadow flags.

Parameters

shadowFlags [in] Input ShadowFlags.

See also: <link gi_shadows_rendering, Shadows Visualization>

Reimplemented from OdGiSubEntityTraits.

◆ setThickness()

void OdGiWorldDrawImpl::setThickness ( double thickness )

virtual

Sets the current thickness.

Parameters

thickness [in] Thickness.

Implements OdGiSubEntityTraits.

◆ setTransparency()

void OdGiWorldDrawImpl::setTransparency ( const OdCmTransparency & transparency )

virtual

Sets the current transparency.

Parameters

transparency [in] OdCmTransparency object.

See also: <exref target="https://docs.opendesign.com/td/cm_transparency_alpha.html">Transparency Functionality as an Alpha-value</exref>; <exref target="https://docs.opendesign.com/td/cm_transparency_integer.html">Transparency Functionality as an Integer-value</exref>

Reimplemented from OdGiSubEntityTraits.

◆ setTrueColor()

void OdGiWorldDrawImpl::setTrueColor ( const OdCmEntityColor & color )

virtual

Sets the current color from an OdCmEntityColor instance.

Parameters

color [in] OdCmEntityColor object.

Implements OdGiSubEntityTraits.

◆ setVisualStyle()

void OdGiWorldDrawImpl::setVisualStyle ( const OdDbStub * visualStyleId )

virtual

Sets the current visual style.

Parameters

visualStyleId [in] Object ID of the visual style.

See also: <link tv_working_with_attributes_visual_styles, Work with Visual Styles>

Reimplemented from OdGiSubEntityTraits.

◆ shadowFlags()

ShadowFlags OdGiWorldDrawImpl::shadowFlags ( ) const

virtual

Retrieves the current ShadowFlags.

Returns: One of the ShadowFlags enumeration values.

See also: <link gi_shadows_rendering, Shadows Visualization>

Reimplemented from OdGiSubEntityTraits.

◆ subEntityTraits()

OdGiSubEntityTraits & OdGiWorldDrawImpl::subEntityTraits ( ) const

virtual

Retrieves sub-entity traits associated with this object.

Returns: sub-entity traits.

Remarks: The subEntityTraits object gives control of, and access to the attribute (color, layer, linetype, etc.) settings of the current geometry. For more information, see the <link OdGiSubEntityTraits, OdGiSubEntityTraits> documentation.

Implements OdGiCommonDraw.

◆ thickness()

double OdGiWorldDrawImpl::thickness ( ) const

virtual

Retrieves the current thickness.

Returns: Current thickness as a value of the double type.

Implements OdGiSubEntityTraits.

◆ transparency()

OdCmTransparency OdGiWorldDrawImpl::transparency ( ) const

virtual

Retrieves the current transparency.

Returns: Transparency as an instance of the OdCmTransparency class.

See also: <exref target="https://docs.opendesign.com/td/cm_transparency_alpha.html">Transparency Functionality as an Alpha-value</exref>; <exref target="https://docs.opendesign.com/td/cm_transparency_integer.html">Transparency Functionality as an Integer-value</exref>

Reimplemented from OdGiSubEntityTraits.

◆ trueColor()

OdCmEntityColor OdGiWorldDrawImpl::trueColor ( ) const

virtual

Retrieves entity color.

Returns: Entity color as OdCmEntityColor instance.

See also: <exref target="https://docs.opendesign.com/td/cm.html">Working with Colors</exref>

Implements OdGiSubEntityTraits.

◆ visualStyle()

OdDbStub * OdGiWorldDrawImpl::visualStyle ( ) const

virtual

Retrieves an identifier of the visual style.

Returns: Pointer to the OdDbStub that represents a visual style identifier.

See also: <link tv_working_with_attributes_visual_styles, Work with Visual Styles>

Reimplemented from OdGiSubEntityTraits.

Member Data Documentation

◆ m_entityTraitsData

OdGiSubEntityTraitsData OdGiWorldDrawImpl::m_entityTraitsData

protected

Definition at line 85 of file GiBaseVectorizer.h.

◆ m_pContext

OdGiContext* OdGiWorldDrawImpl::m_pContext

protected

Definition at line 86 of file GiBaseVectorizer.h.

The documentation for this class was generated from the following file:

GiBaseVectorizer.h

Public Member Functions

Static Public Member Functions

Protected Member Functions

Protected Attributes

Additional Inherited Members

Detailed Description

Constructor & Destructor Documentation

◆ OdGiWorldDrawImpl()

Member Function Documentation

◆ auxData()

◆ color()

◆ context()

◆ drawFlags()

◆ dummyGiContext()

◆ fill()

◆ fillType()

◆ layer()

◆ lineStyleModifiers()

◆ lineType()

◆ lineTypeScale()

◆ lineWeight()

◆ lockFlags()

◆ mapper()

◆ material()

◆ numberOfIsolines()

◆ ODRX_USING_HEAP_OPERATORS()

◆ plotStyleNameId()

◆ plotStyleNameType()

◆ rawGeometry()

◆ secondaryTrueColor()

◆ sectionable()

◆ selectionFlags()

◆ selectionGeom()

◆ setAuxData()

◆ setColor()

◆ setContext()

◆ setDrawFlags()

◆ setFill()

◆ setFillType()

◆ setLayer()

◆ setLineStyleModifiers()

◆ setLineType()

◆ setLineTypeScale()

◆ setLineWeight()

◆ setLockFlags()

◆ setMapper()

◆ setMaterial()

◆ setPlotStyleName()

◆ setSecondaryTrueColor()

◆ setSectionable()

◆ setSelectionFlags()

◆ setSelectionGeom()

◆ setSelectionMarker()

◆ setShadowFlags()

◆ setThickness()

◆ setTransparency()

◆ setTrueColor()

◆ setVisualStyle()

◆ shadowFlags()

◆ subEntityTraits()

◆ thickness()

◆ transparency()

◆ trueColor()

◆ visualStyle()

Member Data Documentation

◆ m_entityTraitsData

◆ m_pContext
