#include <GsLayerNode.h>

Inheritance diagram for OdGiLayerTraitsTakerView:

Public Member Functions
	OdGiLayerTraitsTakerView (OdGsViewImpl &view, const OdGiLayerTraitsTaker *pInheritTaker=NULL)

OdGiViewport &	viewport () const

OdUInt32	sequenceNumber () const

bool	isValidId (const OdUInt32 acgiId) const

OdDbStub *	viewportObjectId () const

virtual OdGeMatrix3d	getModelToEyeTransform () const

virtual OdGeMatrix3d	getEyeToModelTransform () const

virtual OdGeMatrix3d	getWorldToEyeTransform () const

virtual OdGeMatrix3d	getEyeToWorldTransform () const

virtual bool	isPerspective () const

virtual bool	doPerspective (OdGePoint3d &pt) const

virtual bool	doInversePerspective (OdGePoint3d &pt) const

virtual void	getNumPixelsInUnitSquare (const OdGePoint3d &pt, OdGePoint2d &pixelDensity, bool bUsePerspective=true) const

virtual OdGePoint3d	getCameraLocation () const

virtual OdGePoint3d	getCameraTarget () const

virtual OdGeVector3d	getCameraUpVector () const

virtual OdGeVector3d	viewDir () const

virtual OdUInt32	viewportId () const

virtual OdInt16	acadWindowId () const

virtual void	getViewportDcCorners (OdGePoint2d &lowerLeft, OdGePoint2d &upperRight) const

virtual bool	getFrontAndBackClipValues (bool &clipFront, bool &clipBack, double &front, double &back) const

virtual double	linetypeScaleMultiplier () const

virtual double	linetypeGenerationCriteria () const

virtual bool	layerVisible (OdDbStub *layerId) const

virtual void	addRef () override

virtual void	release () ODRX_NOEXCEPT override

virtual double	deviation (const OdGiDeviationType type, const OdGePoint3d &pt) const

virtual OdUInt32	numberOfIsolines () const

virtual OdGiRegenType	regenType () const

virtual bool	regenAbort () const

virtual OdGiContext *	context () const

Public Member Functions inherited from OdGiLayerTraitsTaker
	OdGiLayerTraitsTaker ()

	OdGiLayerTraitsTaker (const OdGiBaseVectorizer pRefView, OdGiContext pContext=NULL)

void	setRefView (const OdGiBaseVectorizer *pRefView)

void	reset (const OdGiLayerTraitsData &ltData=OdGiLayerTraitsData())

OdDb::LineWeight	lineweight () const

OdDbStub *	linetype () const

OdDb::PlotStyleNameType	plotStyleNameType () const

OdDbStub *	plotStyleNameId () const

OdDbStub *	materialId () const

void	setColor (const OdCmEntityColor &color)

void	setLineweight (OdDb::LineWeight lineweight)

void	setLinetype (OdDbStub *pLinetypeId)

void	setPlotStyleName (OdDb::PlotStyleNameType plotStyleNameType, OdDbStub *pPlotStyleNameId=0)

bool	isOff () const

void	setOff (bool bVal)

bool	isPlottable () const

void	setPlottable (bool bVal)

bool	isLocked () const

void	setLocked (bool bVal)

OdCmEntityColor	trueColor () const

OdDbStub *	layer () const

OdDbStub *	lineType () const

OdGiFillType	fillType () const

OdDb::LineWeight	lineWeight () const

double	lineTypeScale () const

double	thickness () const

OdDbStub *	material () const

const OdGiMapper *	mapper () const

OdDbStub *	visualStyle () const

OdCmTransparency	transparency () const

OdUInt32	drawFlags () const

bool	selectionGeom () const

ShadowFlags	shadowFlags () const

bool	sectionable () const

SelectionFlags	selectionFlags () const

void	setTrueColor (const OdCmEntityColor &color)

void	setColor (OdUInt16 color)

void	setLineType (OdDbStub *lineTypeId)

void	setLineWeight (OdDb::LineWeight lineWeight)

void	setMaterial (OdDbStub *pMaterialId)

void	setTransparency (const OdCmTransparency &transparency)

OdCmEntityColor	secondaryTrueColor () const

const OdGiDgLinetypeModifiers *	lineStyleModifiers () const

const OdGiFill *	fill () const

OdGiSubEntityTraits &	subEntityTraits () const

OdGiGeometry &	rawGeometry () const

bool	isDragging () const

void	setContext (OdGiContext *pContext)

OdGeMatrix3d	getModelToWorldTransform () const

OdGeMatrix3d	getWorldToModelTransform () const

virtual OdGiAuxiliaryDataPtr	auxData () const

virtual void	setAuxData (const OdGiAuxiliaryDataPtr &pAuxData)

Public Member Functions inherited from OdGiLayerTraits
	ODRX_DECLARE_MEMBERS (OdGiLayerTraits)

Public Member Functions inherited from OdGiDrawableTraits
	ODRX_DECLARE_MEMBERS (OdGiDrawableTraits)

Public Member Functions inherited from OdRxObject
	ODRX_HEAP_OPERATORS ()

	OdRxObject ()

virtual	~OdRxObject ()

virtual OdRxObject *	queryX (const OdRxClass *pClass) const

virtual OdRxObject *	x (const OdRxClass *pClass) const

virtual OdRxClass *	isA () const

virtual long	numRefs () const

bool	isKindOf (const OdRxClass *pClass) const

virtual OdRxObjectPtr	clone () const

virtual void	copyFrom (const OdRxObject *pSource)

virtual OdRx::Ordering	comparedTo (const OdRxObject *pOther) const

virtual bool	isEqualTo (const OdRxObject *pOther) const

Public Member Functions inherited from OdGiDummyWorldGeometry< OdGiWorldDraw_ >
virtual void	setExtents (const OdGePoint3d *newExtents)

virtual void	startAttributesSegment ()

Public Member Functions inherited from OdGiDummyGeometry< OdGiWorldDraw_ >
void	circle (const OdGePoint3d &center, double radius, const OdGeVector3d &normal)

void	circle (const OdGePoint3d &firstPoint, const OdGePoint3d &secondPoint, const OdGePoint3d &thirdPoint)

void	circularArc (const OdGePoint3d &center, double radius, const OdGeVector3d &normal, const OdGeVector3d &startVector, double sweepAngle, OdGiArcType arcType=kOdGiArcSimple)

void	circularArc (const OdGePoint3d &firstPoint, const OdGePoint3d &secondPoint, const OdGePoint3d &thirdPoint, OdGiArcType arcType=kOdGiArcSimple)

void	polyline (OdInt32 numVertices, const OdGePoint3d vertexList, const OdGeVector3d pNormal=0, OdGsMarker baseSubEntMarker=-1)

void	polygon (OdInt32 numVertices, const OdGePoint3d *vertexList)

void	polygon (OdInt32 numVertices, const OdGePoint3d vertexList, const OdGeVector3d pNormal)

void	pline (const OdGiPolyline &polylPine, OdUInt32 fromIndex=0, OdUInt32 numSegs=0)

void	shape (const OdGePoint3d &position, const OdGeVector3d &normal, const OdGeVector3d &direction, int shapeNumber, const OdGiTextStyle *pTextStyle)

void	text (const OdGePoint3d &position, const OdGeVector3d &normal, const OdGeVector3d &direction, double height, double width, double oblique, const OdString &msg)

void	text (const OdGePoint3d &position, const OdGeVector3d &normal, const OdGeVector3d &direction, const OdChar msg, OdInt32 length, bool raw, const OdGiTextStyle pTextStyle)

void	xline (const OdGePoint3d &firstPoint, const OdGePoint3d &secondPoint)

void	ray (const OdGePoint3d &basePoint, const OdGePoint3d &throughPoint)

void	nurbs (const OdGeNurbCurve3d &nurbsCurve)

void	ellipArc (const OdGeEllipArc3d &ellipArc, const OdGePoint3d *endPointsOverrides=0, OdGiArcType arcType=kOdGiArcSimple)

void	mesh (OdInt32 numRows, OdInt32 numColumns, const OdGePoint3d vertexList, const OdGiEdgeData pEdgeData=0, const OdGiFaceData pFaceData=0, const OdGiVertexData pVertexData=0)

void	shell (OdInt32 numVertices, const OdGePoint3d vertexList, OdInt32 faceListSize, const OdInt32 faceList, const OdGiEdgeData pEdgeData=0, const OdGiFaceData pFaceData=0, const OdGiVertexData *pVertexData=0)

void	worldLine (const OdGePoint3d points[2])

void	image (const OdGiImageBGRA32 &img, const OdGePoint3d &origin, const OdGeVector3d &uVec, const OdGeVector3d &vVec, OdGiRasterImage::TransparencyMode trpMode=OdGiRasterImage::kTransparency8Bit)

virtual void	edge (const OdGiEdge2dArray &edges)

void	polypoint (OdInt32 numPoints, const OdGePoint3d vertexList, const OdCmEntityColor pColors, const OdCmTransparency pTransparency, const OdGeVector3d pNormals, const OdGsMarker *pSubEntMarkers, OdInt32 nPointSize)

virtual void	polyPolygon (OdUInt32 numIndices, const OdUInt32 pNumPositions, const OdGePoint3d pPositions, const OdUInt32 pNumPoints, const OdGePoint3d pPoints, const OdCmEntityColor pOutlineColors=NULL, const OdUInt32 pOutlinePsLinetypes=NULL, const OdCmEntityColor pFillColors=NULL, const OdCmTransparency pFillTransparencies=NULL)

void	rowOfDots (OdInt32 numPoints, const OdGePoint3d &startPoint, const OdGeVector3d &dirToNextPoint)

void	pointCloud (const OdGiPointCloud &pCloud)

void	pushClipBoundary (OdGiClipBoundary *pBoundary)

void	popClipBoundary ()

void	draw (const OdGiDrawable *pDrawable)

void	pushModelTransform (const OdGeMatrix3d &xMat)

void	pushModelTransform (const OdGeVector3d &normal)

void	popModelTransform ()

bool	brep (const OdGiBrep &)

Public Member Functions inherited from OdGiWorldDraw_
OdGiWorldGeometry &	geometry () const

const OdGiPathNode *	currentGiPath () const

Public Member Functions inherited from OdGiWorldDraw
	ODRX_DECLARE_MEMBERS (OdGiWorldDraw)

Public Member Functions inherited from OdGiCommonDraw
	ODRX_DECLARE_MEMBERS (OdGiCommonDraw)

virtual bool	displayModelerSilhouettes () const

Public Member Functions inherited from OdGiWorldGeometry
	ODRX_DECLARE_MEMBERS (OdGiWorldGeometry)

Public Member Functions inherited from OdGiGeometry
	ODRX_DECLARE_MEMBERS (OdGiGeometry)

virtual void	pushClipBoundary (OdGiClipBoundary pBoundary, OdGiAbstractClipBoundary pClipInfo)

ODRX_SEALED_VIRTUAL void	polypoint (OdInt32 numPoints, const OdGePoint3d vertexList, const OdCmEntityColor pColors, const OdGeVector3d pNormals=NULL, const OdGsMarker pSubEntMarkers=NULL) ODRX_FINAL

ODRX_SEALED_VIRTUAL void	polypoint (OdInt32 numPoints, const OdGePoint3d vertexList, const OdGeVector3d pNormals=NULL, const OdGsMarker *pSubEntMarkers=NULL) ODRX_FINAL

Public Member Functions inherited from OdGiWrapperViewportGeometry< OdGiViewportDraw_ >
virtual void	polylineEye (OdUInt32 numVertices, const OdGePoint3d *vertexList)

virtual void	polygonEye (OdUInt32 numVertices, const OdGePoint3d *vertexList)

virtual void	polylineDc (OdUInt32 numVertices, const OdGePoint3d *vertexList)

virtual void	polygonDc (OdUInt32 numVertices, const OdGePoint3d *vertexList)

virtual void	rasterImageDc (const OdGePoint3d &origin, const OdGeVector3d &u, const OdGeVector3d &v, const OdGiRasterImage pImage, const OdGePoint2d uvBoundary, OdUInt32 numBoundPts, bool transparency=false, double brightness=50.0, double contrast=50.0, double fade=0.0)

virtual void	metafileDc (const OdGePoint3d &origin, const OdGeVector3d &u, const OdGeVector3d &v, const OdGiMetafile *pMetafile, bool dcAligned=true, bool allowClipping=false)

virtual void	ownerDrawDc (const OdGePoint3d &origin, const OdGeVector3d &u, const OdGeVector3d &v, const OdGiSelfGdiDrawable *pDrawable, bool dcAligned=true, bool allowClipping=false)

Public Member Functions inherited from OdGiWrapperGeometry< OdGiViewportDraw_ >
virtual void	pline (const OdGiPolyline &p, OdUInt32 i, OdUInt32 n)

virtual void	pushModelTransform (const OdGeVector3d &vNormal)

virtual void	pushModelTransform (const OdGeMatrix3d &xMat)

virtual void	popModelTransform ()

virtual void	circle (const OdGePoint3d &center, double radius, const OdGeVector3d &normal)

virtual void	circle (const OdGePoint3d &p1, const OdGePoint3d &p2, const OdGePoint3d &p3)

virtual void	circularArc (const OdGePoint3d &center, double radius, const OdGeVector3d &normal, const OdGeVector3d &startVector, double sweepAngle, OdGiArcType arcType=kOdGiArcSimple)

virtual void	circularArc (const OdGePoint3d &start, const OdGePoint3d &point, const OdGePoint3d &end, OdGiArcType arcType=kOdGiArcSimple)

virtual void	polyline (OdInt32 nbPoints, const OdGePoint3d pVertexList, const OdGeVector3d pNormal=NULL, OdGsMarker lBaseSubEntMarker=-1)

virtual void	polygon (OdInt32 nbPoints, const OdGePoint3d *pVertexList)

virtual void	polygon (OdInt32 nbPoints, const OdGePoint3d pVertexList, const OdGeVector3d pNormal)

virtual void	mesh (OdInt32 rows, OdInt32 columns, const OdGePoint3d pVertexList, const OdGiEdgeData pEdgeData=NULL, const OdGiFaceData pFaceData=NULL, const OdGiVertexData pVertexData=NULL)

virtual void	shell (OdInt32 nbVertex, const OdGePoint3d pVertexList, OdInt32 faceListSize, const OdInt32 pFaceList, const OdGiEdgeData pEdgeData=NULL, const OdGiFaceData pFaceData=NULL, const OdGiVertexData *pVertexData=NULL)

virtual void	text (const OdGePoint3d &position, const OdGeVector3d &normal, const OdGeVector3d &direction, double height, double width, double oblique, const OdString &msg)

virtual void	text (const OdGePoint3d &position, const OdGeVector3d &normal, const OdGeVector3d &direction, const OdChar msg, OdInt32 length, bool raw, const OdGiTextStyle pTextStyle)

void	ray (const OdGePoint3d &first, const OdGePoint3d &second)

virtual void	nurbs (const OdGeNurbCurve3d &nurbs)

virtual void	xline (const OdGePoint3d &p1, const OdGePoint3d &p2)

virtual void	ellipArc (const OdGeEllipArc3d &arc, const OdGePoint3d *pEndPointsOverrides=0, OdGiArcType arcType=kOdGiArcSimple)

virtual void	draw (const OdGiDrawable *pD)

virtual void	pushClipBoundary (OdGiClipBoundary *pBoundary)

virtual void	popClipBoundary ()

virtual void	worldLine (const OdGePoint3d pnts[2])

virtual void	image (const OdGiImageBGRA32 &img, const OdGePoint3d &origin, const OdGeVector3d &uVec, const OdGeVector3d &vVec, OdGiRasterImage::TransparencyMode trpMode=OdGiRasterImage::kTransparency8Bit)

virtual void	edge (const OdGiEdge2dArray &edges)

virtual void	polypoint (OdInt32 numPoints, const OdGePoint3d vertexList, const OdCmEntityColor pColors, const OdCmTransparency pTransparency, const OdGeVector3d pNormals, const OdGsMarker *pSubEntMarkers, OdInt32 nPointSize)

virtual void	polyPolygon (OdUInt32 numIndices, const OdUInt32 pNumPositions, const OdGePoint3d pPositions, const OdUInt32 pNumPoints, const OdGePoint3d pPoints, const OdCmEntityColor pOutlineColors=NULL, const OdUInt32 pOutlinePsLinetypes=NULL, const OdCmEntityColor pFillColors=NULL, const OdCmTransparency pFillTransparencies=NULL)

virtual void	rowOfDots (OdInt32 numPoints, const OdGePoint3d &startPoint, const OdGeVector3d &dirToNextPoint)

virtual void	pointCloud (const OdGiPointCloud &pCloud)

virtual bool	brep (const OdGiBrep &giBrep)

Public Member Functions inherited from OdGiViewportDraw_
OdGiViewportGeometry &	geometry () const

const OdGiPathNode *	currentGiPath () const

Public Member Functions inherited from OdGiViewportDraw
	ODRX_DECLARE_MEMBERS (OdGiViewportDraw)

Public Member Functions inherited from OdGiViewportGeometry
	ODRX_DECLARE_MEMBERS (OdGiViewportGeometry)

Public Member Functions inherited from OdGiDummySubEntityTraits< OdGiSubEntityTraits >
void	setLayer (OdDbStub *layerId)

void	setSelectionMarker (OdGsMarker selectionMarker)

void	setFillType (OdGiFillType fillType)

void	setFillPlane (const OdGeVector3d *pNormal=0)

void	setLineTypeScale (double lineTypeScale=1.0)

void	setThickness (double thickness)

void	setMapper (const OdGiMapper *pMapper)

void	setVisualStyle (const OdDbStub *visualStyleId)

void	setDrawFlags (OdUInt32 drawFlags)

void	setLockFlags (OdUInt32 lockFlags)

void	setSelectionGeom (bool bSelectionFlag)

void	setShadowFlags (OdGiSubEntityTraits::ShadowFlags shadowFlags)

void	setSectionable (bool bSectionableFlag)

void	setSelectionFlags (OdGiSubEntityTraits::SelectionFlags selectionFlags)

bool	fillPlane (OdGeVector3d &normal)

void	addLight (const OdDbStub *)

OdUInt32	lockFlags () const

Public Member Functions inherited from OdGiSubEntityTraits
	ODRX_DECLARE_MEMBERS (OdGiSubEntityTraits)

virtual void	setSecondaryTrueColor (const OdCmEntityColor &color)

virtual void	setLineStyleModifiers (const OdGiDgLinetypeModifiers *pLSMod)

virtual void	setFill (const OdGiFill *pFill)

virtual bool	pushLineweightOverride (const OdGiLineweightOverride *pOverride)

virtual void	popLineweightOverride ()

virtual bool	pushPaletteOverride (const OdGiPalette *pOverride)

virtual void	popPaletteOverride ()

virtual OdUInt32	setupForEntity () const

Public Member Functions inherited from OdGiLayerTraitsData
	OdGiLayerTraitsData ()

OdGiLayerTraitsData &	operator= (const OdGiLayerTraitsData &other)=default

OdUInt32	flags () const

OdDb::LineWeight	lineweight () const

OdDbStub *	linetype () const

OdDb::PlotStyleNameType	plotStyleNameType () const

OdDbStub *	plotStyleNameId () const

const OdCmEntityColor &	trueColor () const

OdDbStub *	materialId () const

OdCmTransparency	transparency () const

void	setTrueColor (const OdCmEntityColor &cl)

void	setLineweight (OdDb::LineWeight lw)

void	setLinetype (OdDbStub *id)

void	setMaterial (OdDbStub *id)

void	setTransparency (const OdCmTransparency &transparency)

bool	isOff () const

void	setOff (bool bVal)

bool	isPlottable () const

void	setPlottable (bool bVal)

bool	isLocked () const

void	setLocked (bool bVal)

bool	isFrozen () const

bool	isByBlock () const

Public Member Functions inherited from OdGiViewport
	ODRX_DECLARE_MEMBERS (OdGiViewport)

virtual const OdGiContextualColors *	contextualColors () const

virtual OdDbStub *	annotationScaleId () const

Protected Attributes
OdGsViewImpl &	m_view

Additional Inherited Members
Public Types inherited from OdGiLayerTraits
enum	{ kByBlock = (OdGiDrawable::kLastFlag << 1) , kFrozen = (OdGiDrawable::kLastFlag << 2) , kOff = (OdGiDrawable::kLastFlag << 3) , kPlottable = (OdGiDrawable::kLastFlag << 4) , kLocked = (OdGiDrawable::kLastFlag << 5) }

Public Types inherited from OdGiSubEntityTraits
enum	DrawFlags { kNoDrawFlags = 0x0000 , kDrawBackfaces = 0x0001 , kDrawHatchGroup = 0x0002 , kDrawFrontfacesOnly = 0x0004 , kDrawGradientFill = 0x0008 , kDrawSolidFill = 0x0010 , kDrawNoLineWeight = 0x0020 , kDrawNoPlotstyle = 0x0080 , kDrawContourFill = 0x08000 , kDisableLayoutCache = 0x10000 , kDrawBoundaryForClipping = 0x20000 , kDrawBoundaryForClippingDrw = 0x40000 , kClipSetIsEmpty = 0x80000 , kDrawPolygonFill = 0x100000 , kExcludeFromViewExt = 0x200000 , kDrawDgLsPolyWithoutBreaks = 0x400000 , kPolygonProcessing = 0x800000 , kDisableAutoGenerateNormals = 0x1000000 , kDisableFillModeCheck = 0x2000000 , kDrawUnderlayReference = 0x4000000 , kLineStyleScaleOverride = 0x8000000 , kDisableDisplayClipping = 0x10000000 , kRegenTypeDependent2dDraw = 0x20000000 , kInternalDrawFlags = kDisableLayoutCache \| kClipSetIsEmpty \| kRegenTypeDependent2dDraw , kDrawGeometryForExtents = 0x04000 , kFxNoFillOnSelect = 0x40000000 , kInheritableDrawFlags }

enum	LockFlags { kNoLockFlags = 0x00000000 , kLockColors = 0x00000001 , kLockLineWeight = 0x00000002 , kLockLineType = 0x00000004 , kLockLineTypeScale = 0x00000008 , kLockLayer = 0x00000010 , kLockByBlockLayer = 0x00000020 , kKeepAuxDataAndLockFlags = 0x00000040 , kInheritableLockFlags = kLockColors \| kLockLineWeight \| kLockLineType \| kLockLineTypeScale \| kLockLayer \| kKeepAuxDataAndLockFlags }

enum	ShadowFlags { kShadowsCastAndReceive = 0 , kShadowsDoesNotCast = 1 , kShadowsDoesNotReceive = 2 , kShadowsIgnore = kShadowsDoesNotCast \| kShadowsDoesNotReceive }

enum	SelectionFlags { kNoSelectionFlags = 0 , kSelectionIgnore = 1 , kHighlightingGeometry = 2 , kHiddenInHighlight = 4 , kFxSubentitySelection = 0x80 }

enum	SubEntityHints { kHint2DAttributes = 1 , kHint3DAttributes = 2 , kHintAllAttributes = kHint2DAttributes \| kHint3DAttributes , kHintSnapModeOn = 4 , kHintDefaultState = kHintAllAttributes }

Static Public Member Functions inherited from OdRxObject
static OdRxObjectPtr	cast (const OdRxObject *pointer)

static OdRxClass *	desc ()

static void	rxInit ()

static void	rxUninit ()

Public Attributes inherited from OdGiLayerTraitsData
OdUInt32	m_flags

OdDb::LineWeight	m_lineweight

OdDb::PlotStyleNameType	m_plotStyleNameType

OdCmEntityColor	m_color

OdDbStub *	m_linetypeId

OdDbStub *	m_plotStyleNameId

OdDbStub *	m_materialId

OdCmTransparency	m_cmTransparency

Protected Member Functions inherited from OdGiLayerTraitsTaker
	ODRX_USING_HEAP_OPERATORS (OdGiDummyWorldDraw< OdGiDummyWorldGeometry< OdGiWorldDraw_ > >)

Protected Member Functions inherited from OdGiLayerTraits_
OdCmEntityColor	color () const

Protected Member Functions inherited from OdGiWorldDraw_
	ODRX_USING_HEAP_OPERATORS (OdGiWorldDraw)

Protected Member Functions inherited from OdGiWrapperGeometry< OdGiViewportDraw_ >
void	setGeom (OdGiGeometry &Geom)

OdGiGeometry &	getGeom ()

Protected Member Functions inherited from OdGiViewportDraw_
	ODRX_USING_HEAP_OPERATORS (OdGiViewportDraw)

Protected Member Functions inherited from OdGiSubEntityTraits_
OdUInt16	color () const

Detailed Description

This is a helper class to substitute OdGiLayerTraitsTaker in OdGsBaseModel::propagateLayerChanges() where vectorizers are not available to be set by setRefView(), and not actually required. <group OdGs_Classes>

Definition at line 335 of file GsLayerNode.h.

Constructor & Destructor Documentation

◆ OdGiLayerTraitsTakerView()

OdGiLayerTraitsTakerView::OdGiLayerTraitsTakerView	(	OdGsViewImpl &	view,
		const OdGiLayerTraitsTaker *	pInheritTaker = NULL )

inline

Constructor for the OdGiLayerTraitsTakerView class.

Parameters

view	[in] Implementation view object.
pInheritTaker	[in] Pointer to the layer traits taker object.

Definition at line 345 of file GsLayerNode.h.

Member Function Documentation

◆ acadWindowId()

virtual OdInt16 OdGiLayerTraitsTakerView::acadWindowId ( ) const

inlinevirtual

Returns the ID for this Viewport object.

Remarks: The value returned corresponds to the CVPORT system variable.

Implements OdGiViewport.

Definition at line 499 of file GsLayerNode.h.

◆ addRef()

virtual void OdGiLayerTraitsTakerView::addRef ( )

inlineoverridevirtual

OdRxObject methods

Adds reference to this object. Does nothing in current implementation.

Reimplemented from OdGiLayerTraitsTaker.

Definition at line 571 of file GsLayerNode.h.

◆ context()

virtual OdGiContext * OdGiLayerTraitsTakerView::context ( ) const

inlinevirtual

Retrieves pointer to a context associated with this object.

Reimplemented from OdGiLayerTraitsTaker.

Definition at line 648 of file GsLayerNode.h.

◆ deviation()

virtual double OdGiLayerTraitsTakerView::deviation	(	const OdGiDeviationType	type,
		const OdGePoint3d &	pt ) const

inlinevirtual

OdGiCommonDraw methods

Retrieves the recommended maximum deviation of the current vectorization for the specified point on a curve.

Parameters

type	[in] Deviation type.
pt	[in] Point on a curve.

Returns: recommended maximum difference (with respect to the current active viewport) between the actual curve or surface, and the tessellated curve or surface.

Remarks: deviationType must be one of the following:

Value kOdGiMaxDevForCircle 0
kOdGiMaxDevForCurve 1
kOdGiMaxDevForBoundary 2
kOdGiMaxDevForIsoline 3 kOdGiMaxDevForFacet 4

Reimplemented from OdGiLayerTraitsTaker.

Definition at line 605 of file GsLayerNode.h.

◆ doInversePerspective()

virtual bool OdGiLayerTraitsTakerView::doInversePerspective ( OdGePoint3d & pt ) const

inlinevirtual

Applies the inverse of the current perspective transformation to the specified point.

Parameters

point [in/out] Any 3D point.

Returns: true if the point was transformed; i.e., a perspective transform is active, and the point was neither too close or behind the camera.

Remarks: The point is transformed from normalized device coordinates to EyeSpace coordinates

Implements OdGiViewport.

Definition at line 449 of file GsLayerNode.h.

◆ doPerspective()

virtual bool OdGiLayerTraitsTakerView::doPerspective ( OdGePoint3d & pt ) const

inlinevirtual

Applies the current perspective transformation to the specified point.

Parameters

point [in/out] Any 3D point.

Returns: true if the point was transformed; i.e., a perspective transform is active, and the point was neither too close or behind the camera.

Remarks: The point is transformed from EyeSpace coordinates to normalized device coordinates.

Implements OdGiViewport.

Definition at line 437 of file GsLayerNode.h.

◆ getCameraLocation()

virtual OdGePoint3d OdGiLayerTraitsTakerView::getCameraLocation ( ) const

inlinevirtual

Returns the WCS camera (eye) location for this Viewport object.

Implements OdGiViewport.

Definition at line 468 of file GsLayerNode.h.

◆ getCameraTarget()

virtual OdGePoint3d OdGiLayerTraitsTakerView::getCameraTarget ( ) const

inlinevirtual

Returns the WCS camera target for this Viewport object.

Implements OdGiViewport.

Definition at line 473 of file GsLayerNode.h.

◆ getCameraUpVector()

virtual OdGeVector3d OdGiLayerTraitsTakerView::getCameraUpVector ( ) const

inlinevirtual

Returns the WCS camera "up" vector for this Viewport object.

Implements OdGiViewport.

Definition at line 478 of file GsLayerNode.h.

◆ getEyeToModelTransform()

virtual OdGeMatrix3d OdGiLayerTraitsTakerView::getEyeToModelTransform ( ) const

inlinevirtual

Returns the transformation matrix from EyeSpace to ModelSpace for this Viewport object.

See also: <link CoordinateSystems, Coordinate Systems>

Implements OdGiViewport.

Definition at line 402 of file GsLayerNode.h.

◆ getEyeToWorldTransform()

virtual OdGeMatrix3d OdGiLayerTraitsTakerView::getEyeToWorldTransform ( ) const

inlinevirtual

Returns the transformation matrix from EyeSpace to WCS for this Viewport object.

See also: <link CoordinateSystems, Coordinate Systems>

Implements OdGiViewport.

Definition at line 418 of file GsLayerNode.h.

◆ getFrontAndBackClipValues()

virtual bool OdGiLayerTraitsTakerView::getFrontAndBackClipValues	(	bool &	clipFront,
		bool &	clipBack,
		double &	front,
		double &	back ) const

inlinevirtual

Returns the front and back clipping parameters for this Viewport object.

Parameters

clipFront	[out] Receives true if and only if front clipping is enabled.
clipBack	[out] Receives true if and only if back clipping is enabled.
front	[out] Receives the front clipping distance.
back	[out] Receives the back clipping distance.

Returns: result of clipFront || clipBack.

Remarks: Front and back are the eye coordinate Z values. Clipping planes are perpendicular to the view direction. If the front clipping plane is enabled, geometry in front of it is not displayed. If the back clipping plane is enabled, geometry in back of it is not displayed.

Implements OdGiViewport.

Definition at line 533 of file GsLayerNode.h.

◆ getModelToEyeTransform()

virtual OdGeMatrix3d OdGiLayerTraitsTakerView::getModelToEyeTransform ( ) const

inlinevirtual

OdGiViewport methods

Returns the transformation matrix from ModelSpace to EyeSpace for this Viewport object.

See also: <link CoordinateSystems, Coordinate Systems>

Implements OdGiViewport.

Definition at line 394 of file GsLayerNode.h.

◆ getNumPixelsInUnitSquare()

virtual void OdGiLayerTraitsTakerView::getNumPixelsInUnitSquare	(	const OdGePoint3d &	pt,
		OdGePoint2d &	pixelDensity,
		bool	bUsePerspective = true ) const

inlinevirtual

Returns the display pixel density at the specified point for this Viewport object.

Parameters

point	[in] WCS center of the unit square.
pixelDensity	[out] Receives the pixel density.
bUsePerspective	[in] Enable perspective inclusion into pixel density calculation.

Remarks: Pixel density is measured in pixels per WCS unit. This function can be used to determine if the geometry generated for an object will be smaller than the size of a pixel.

Implements OdGiViewport.

Definition at line 462 of file GsLayerNode.h.

◆ getViewportDcCorners()

virtual void OdGiLayerTraitsTakerView::getViewportDcCorners	(	OdGePoint2d &	lowerLeft,
		OdGePoint2d &	upperRight ) const

inlinevirtual

Returns lower-left and upper-right corners of this Viewport object in normalized device Coordinates.

Parameters

lowerLeft	[out] Receives the lower-left corner.
upperRight	[out] Receives the upper-right.

Remarks: This information lets position items that are fixed in size and/or position with respect to a Viewport.

Implements OdGiViewport.

Definition at line 515 of file GsLayerNode.h.

◆ getWorldToEyeTransform()

virtual OdGeMatrix3d OdGiLayerTraitsTakerView::getWorldToEyeTransform ( ) const

inlinevirtual

Returns the transformation matrix from WCS to EyeSpace for this Viewport object.

See also: <link CoordinateSystems, Coordinate Systems>

Implements OdGiViewport.

Definition at line 410 of file GsLayerNode.h.

◆ isPerspective()

virtual bool OdGiLayerTraitsTakerView::isPerspective ( ) const

inlinevirtual

Checks whether perspective mode is turned on for this Viewport.

Returns: true if perspective mode is on for this Viewport, false otherwise.

Implements OdGiViewport.

Definition at line 425 of file GsLayerNode.h.

◆ isValidId()

bool OdGiLayerTraitsTakerView::isValidId ( const OdUInt32 acgiId ) const

inlinevirtual

Returns true if and only if specified Viewport ID is a valid Viewport ID.

Parameters

viewportId [in] Viewport ID.

Remarks: viewportId is typically obtained from viewport().viewportId().

Reimplemented from OdGiLayerTraitsTaker.

Definition at line 374 of file GsLayerNode.h.

◆ layerVisible()

virtual bool OdGiLayerTraitsTakerView::layerVisible ( OdDbStub * layerId ) const

inlinevirtual

Checks whether the specified layer is not frozen either globally or in this Viewport object.

Parameters

layerId [in] Object ID of OdLayerTableRecord.

Returns: true if the specified layer is not frozen either globally or in this Viewport object, false otherwise.

Implements OdGiViewport.

Definition at line 562 of file GsLayerNode.h.

◆ linetypeGenerationCriteria()

virtual double OdGiLayerTraitsTakerView::linetypeGenerationCriteria ( ) const

inlinevirtual

Returns the WCS value below which linetype generation is not used.

Remarks: If the WCS length an entire linetype pattern is less than the returned value, then the linetype will be rendered as continuous.

Implements OdGiViewport.

Definition at line 553 of file GsLayerNode.h.

◆ linetypeScaleMultiplier()

virtual double OdGiLayerTraitsTakerView::linetypeScaleMultiplier ( ) const

inlinevirtual

Returns a multiplier that is used to scale all linetypes in this Viewport object.

Implements OdGiViewport.

Definition at line 544 of file GsLayerNode.h.

◆ numberOfIsolines()

virtual OdUInt32 OdGiLayerTraitsTakerView::numberOfIsolines ( ) const

inlinevirtual

Retrieves the number of isolines to be drawn on surfaces during this vectorization.

Remarks: Isolines are lines or curves which are used to represent the entity. For example, if an entity is a sphere and this method returns 3, the sphere should be displayed as 3 circles with a common center and planes that are perpendicular to each other.

Reimplemented from OdGiLayerTraitsTaker.

Definition at line 616 of file GsLayerNode.h.

◆ regenAbort()

virtual bool OdGiLayerTraitsTakerView::regenAbort ( ) const

inlinevirtual

Checks whether this vectorization process should be aborted.

Returns: true if this vectorization process should be aborted.

Reimplemented from OdGiLayerTraitsTaker.

Definition at line 643 of file GsLayerNode.h.

◆ regenType()

virtual OdGiRegenType OdGiLayerTraitsTakerView::regenType ( ) const

inlinevirtual

Retrieves the regeneration type of the current vectorization process.

Returns: one of the following regeneration types:

Value eOdGiRegenTypeInvalid 0 kOdGiStandardDisplay 2 kOdGiHideOrShadeCommand 3 kOdGiRenderCommand 4 kOdGiForExplode 5 kOdGiSaveWorldDrawForProxy 6 kOdGiForExtents 7

Reimplemented from OdGiLayerTraitsTaker.

Definition at line 635 of file GsLayerNode.h.

◆ release()

virtual void OdGiLayerTraitsTakerView::release ( )

inlineoverridevirtual

Releases reference to this object. Does nothing in current implementation.

Reimplemented from OdGiLayerTraitsTaker.

Definition at line 576 of file GsLayerNode.h.

◆ sequenceNumber()

OdUInt32 OdGiLayerTraitsTakerView::sequenceNumber ( ) const

inlinevirtual

Returns the number of viewports that have been deleted from the current database during this editing session.

Reimplemented from OdGiLayerTraitsTaker.

Definition at line 364 of file GsLayerNode.h.

◆ viewDir()

virtual OdGeVector3d OdGiLayerTraitsTakerView::viewDir ( ) const

inlinevirtual

Returns the vector from the camera target to the camera location.

Implements OdGiViewport.

Definition at line 483 of file GsLayerNode.h.

◆ viewport()

OdGiViewport & OdGiLayerTraitsTakerView::viewport ( ) const

inlinevirtual

OdGiViewportDraw methods

Returns a reference to the OdGiViewport object associated with this object.

Remarks: The OdGiViewport contains information specific to the viewport being drawn.

Reimplemented from OdGiLayerTraitsTaker.

Definition at line 358 of file GsLayerNode.h.

◆ viewportId()

virtual OdUInt32 OdGiLayerTraitsTakerView::viewportId ( ) const

inlinevirtual

Returns the OdGi Viewport ID for this Viewport object.

Remarks: The value returned has no relationshp to the CVPORT system variable.

Implements OdGiViewport.

Definition at line 491 of file GsLayerNode.h.

◆ viewportObjectId()

OdDbStub * OdGiLayerTraitsTakerView::viewportObjectId ( ) const

inlinevirtual

Returns the Object ID of the OdDbViewport object associated with this object.

Remarks: Returns NULL if TileMode == 1.

Reimplemented from OdGiLayerTraitsTaker.

Definition at line 382 of file GsLayerNode.h.

Member Data Documentation

◆ m_view

OdGsViewImpl& OdGiLayerTraitsTakerView::m_view

protected

Definition at line 650 of file GsLayerNode.h.

The documentation for this class was generated from the following file:

GsLayerNode.h

Public Member Functions

Protected Attributes

Additional Inherited Members

Detailed Description

Constructor & Destructor Documentation

◆ OdGiLayerTraitsTakerView()

Member Function Documentation

◆ acadWindowId()

◆ addRef()

◆ context()

◆ deviation()

◆ doInversePerspective()

◆ doPerspective()

◆ getCameraLocation()

◆ getCameraTarget()

◆ getCameraUpVector()

◆ getEyeToModelTransform()

◆ getEyeToWorldTransform()

◆ getFrontAndBackClipValues()

◆ getModelToEyeTransform()

◆ getNumPixelsInUnitSquare()

◆ getViewportDcCorners()

◆ getWorldToEyeTransform()

◆ isPerspective()

◆ isValidId()

◆ layerVisible()

◆ linetypeGenerationCriteria()

◆ linetypeScaleMultiplier()

◆ numberOfIsolines()

◆ regenAbort()

◆ regenType()

◆ release()

◆ sequenceNumber()

◆ viewDir()

◆ viewport()

◆ viewportId()

◆ viewportObjectId()

Member Data Documentation

◆ m_view
